  • Blue Gel Seal Mini Pleat HEPA Air Filter

    Clapboard:withoutClapboardFilterNumber:1MediumMaterial:FiberglassEfficiency:H13FiltrationGrade:HEPAFilterType:GelSealMini-PleatPanelFilter
    Air Filter With V Cell Structure In Header Type Photos 1655262226

    Model NO.
    HMG
    Structure
    L-Type Side Gel Seal, Y-Type Top Gel Seal
    Media
    Ultra-Fine Fiberglass Filter Paper
    Frame
    Anodized Aluminum Alloy
    Separator
    Hot-Melt Glue
    Temperature
    Maximum 90°c in Continuous Service
    Transport Package
    Carton / Wooden Case
    Specification
    508X552X120MM
    Trademark
    KOSAFILTER
    Origin
    China
    HS Code
    8421399090
    Production Capacity
    2500PCS

    Air Purification System Air Cleaner Ac Filter Carbon Active Filter Photos 1655256071

    Product Description





    Application
    Suitable for electronics, pharmaceutical industry, clean room, HEPA diffuser, laminar flow devices and the occasions require ultra-high cleanliness.
    Material Instructions
    Structure: L-type side gel seal, Y-type top gel seal.
    Media: Ultra-fine fiberglass filter paper.
    Frame: Anodized aluminum alloy.
    Separator: Hot-melt glue.
    Sealant: Polyurethane.
    Temperature: Maximum 90°C in continuous service.
    Advantages
    Filter efficiency ranges from H14 to U17.
    Adopt computer-controlled automatic production line for manufacturing, the crest height of folding filter material can be regulated steplessly between 18~96 mm, width will reach 1240mm at the widest.
    Use special ultra-fine fiberglass paper as the filter media, good stability of filtration efficiency.
    Double side retainers, protect the filter material, good strength.
    Light in weight, compact in structure.
    Each ULPA/HEPA filter is tested according to EN1822:2009.
    Structure Drawings



    Common Specifications
    Model Dimensions Media Area
    (m2)    		 Rated Air Flow
    (m3/h)    		 Initial Pressure Drop
    (Pa)
    W×H×D (mm)
    HMG610/10-70L 610×610×70 9.5 800 ≤220
    HMG610/03-93L 305×305×93 2.7 250
    HMG610/05-93L 305×610×93 5.9 500
    HMG610/10-93L 610×610×93 13.0 1000
    HMG610/15-93L 915×610×93 20.0 1500
    HMG610/20-93L 1220×610×93 27.0 2000
    HMG610/03-104Y 305×305×104 3.4 320 ≤250
    HMG610/05-104Y 305×610×104 6.8 640
    HMG610/10-104Y 610×610×104 13.9 1280
    HMG610/15-104Y 915×610×104 20.9 1920
    HMG610/20-104Y 1220×610×104 28.0 2560
    KOSAFILTER makes various of other models' HMG filter which are not listed in above table. Please consult with us if you need.

    The Initial Pressure Drop and Rated Air Flow Performance Curve
