  • Horizontal Laminar Flow Bench Price

    InstallationMethod:HorizontalOperationType:AutomaticMediumMaterial:GlassfiberBoxMaterial:WallPlate,SprayColdRolledSteelPlateetcInstallation:SuspensionorBracketSupportTransportPackage:CartonandWoodenCase


    Model NO.
    HLB
    • Trademark
    KOSAFILTER
    Origin
    Shanghai
    HS Code
    8414809053


    Product Description


    Advantages
    1.Can be lifted over the process point that requires high cleanliness to meet the requirements of local high level cleanliness.
    2.Outer casing can be made of cold-rolled steel or stainless steel sheet.
    3.Use double-speed and high pressure fan, which is with the feature of small size, large air volume, high pressure, low noise etc.
    4.It consists of high-quality primary-efficiency panel filter and mini-pleat HEPA panel filter.
    5.Can be used alone or can be composed into multiple parallel and work as clean laminar flow zoon.
    6.Installation mode: Suspension or brace.
    7.Less investment, faster effect, easy to installation and low operating costs.
    8.Cleanliness: ISO Class 5 / FS209E Class 100 (≥0.5μm dust particles ≤ 3.5 A/l).
    9.Air velocity: 0.35~0.55m/s.
    10.Noise: ≤64dB (A).
    Material Instructions
    Casing material: Sandwich panel, cold-rolled steel or stainless steel sheet.
    Casing material: Cold-rolled steel or stainless steel sheet.
    Fan: Specialized centrifugal fan.
    Filtration system: Consists of high-quality primary-efficiency panel filter and mini-pleat HEPA panel filter, overall efficiency reaches 99.99%@0.3um.
     Application
    Mainly used to clean and sterile operating environment of electronics, biology, medicine, food, precision instruments, provide high level cleanliness of the local environment.

    Common Specifications
    ModelRated Air Flow
    (m3/h)    		Dimensions
    L×W×H (mm)    		Working Area
    (mm)
    HEPA Specification    		Power Supply and Dissipation
    HLB1220/61012001360×740×8501220×610610×610×150 (mm)
    2pcs    		AC
    1Ф-220V/50Hz
    (1Ф-110V/60Hz)    		1.0kW
    HBL1220/91518001360×1040×8501220×915915×610×150 (mm)
    2pcs    		1.1kW
    HBL1220/122024001360×1360×8501220×12201219×610×150 (mm)
    2pcs    		1.3kW
    HBL2500/91548003200×1040×6002500×915915×610×150 (mm)
    4pcs    		AC
    3Ф-380V/50Hz
    (3Ф-200V/60Hz)    		1.8kW

    Note: 1. In case of specifications or structures changes, KOSA will provide up-to-date data on website: www.kosafilter.com.
         2. KOSA makes various of other models' HLB filter not listed in above table. Please consult with us if you need.
